PG-L25 Wheeled Skid Steer Loader
PG-L25 Wheeled Skid Steer Loader
Couldn't load pickup availability
Engines Available: Kubota, Perkins and Yuchai.
Make your productivity to the next level with the PG-L25 Compact Loader — a powerful, manoeuvrable, and efficient machine engineered for tight spaces and tough jobs. Whether you’re in construction, landscaping, agriculture, or material handling, the PG-L25 delivers the lifting strength, stability, and control you need to get the job done right.
Compact Design, Maximum Efficiency
Designed for performance in confined environments, the PG-L25 combines compact dimensions with impressive reach and dump height capabilities.
Overall Operating Height: 3050 mm
Dumping Height: 2150 mm
Dumping Reach: 560 mm
Height to Bucket Hinge Pin: 2580 mm
The result? Easy loading into trucks, trailers, or bins — all while maintaining excellent visibility and balance.
Built for Strength & Stability
Despite its small footprint, the PG-L25 is built tough. With a wheelbase of 760 mm and ground clearance of 120 mm, this machine ensures stability on uneven terrain. Its 10° departure angle and tight turning radius (as small as 1025 mm) make it incredibly nimble — perfect for working in narrow job sites, barns, or yards where larger machines can’t go.
Smooth, Controlled Operation
The PG-L25 offers superior control and lifting geometry designed for safe, smooth operation:
23° Dumping Angle at Maximum Height
33° Rollback on Ground for strong bucket retention
45° Rollback at Full Height for secure material handling
These optimized angles help prevent material spillage while ensuring clean, efficient loading and unloading.
Compact Yet Capable
At just 2570 mm in overall length (with bucket) and 1065 mm in width, the PG-L25 fits easily through gates and between obstacles. Its bucket width of 1010 mm offers excellent capacity for its size, making it the perfect choice for gravel, soil, mulch, feed, or debris.
Key Specifications
| Specification | Value |
|---|---|
| Model | PG-L25 |
| Operating Height | 3050 mm |
| Height to Bucket Hinge Pin | 2580 mm |
| Dumping Height | 2150 mm |
| Dumping Reach | 560 mm |
| Wheelbase | 760 mm |
| Ground Clearance | 120 mm |
| Turning Radius (front) | 1560 mm |
| Machine Width | 1065 mm |
| Bucket Width | 1010 mm |
| Overall Length (with bucket) | 2570 mm |
Why Choose the PG-L25 Compact Loader?
✅ Compact and agile for tight workspaces
✅ Efficient lift height for truck and trailer loading
✅ Smooth bucket control with optimized rollback angles
✅ Strong, stable chassis built for demanding conditions
✅ Ideal for contractors, landscapers, and small farm operators
