Key Features
Powerful Kubota Euro 5 diesel engine for reliable, low-emission performance
Danfoss hydrostatic transmission system (HST) with dual axles
Four-wheel drive (4WD) and four-wheel steering (4WS) for exceptional manoeuvrability
Quick hitch system for rapid attachment changes
Standard 3.5-ton forks (1,070 mm) included
Full electric proportional joystick with Load Sensing (LS) system for precise hydraulic control
Electric gear shift for smooth and efficient operation
Limited-slip differential for improved traction
Overload alarm system for enhanced operational safety
Floating function for improved surface tracking
Cab & Operator Comfort
Premium luxury cab interior
Ergonomic comfortable operator seat
HD display for real-time machine monitoring
Rear-view camera for increased safety and visibility
Push-button start with Bluetooth key access
Hand throttle for precise engine speed control
LED working lights for excellent visibility in all conditions
Braking & Safety Systems
Heavy-duty Carraro wet brake axles
Hydraulic oil cut-off braking system
Electric hand brake for secure parking
Performance & Capacity
Maximum tipping load: 2,800 kg
Net operating weight: 5,700 kg
Maximum lifting height (shovel pivot pin): 6,214 mm
Dimensions & Manoeuvrability
Overall dimensions (L × W × H): 4,048 × 1,843 × 2,033 mm
Minimum turning radius:
Inner: 1,598 mm
Outer: 3,274 mm (without forks)
Outside turning radius: 3,310 mm
Hydraulic System
Drive pump rated pressure: 400 bar
Working pump flow: 105.6 L/min
Working pump rated pressure: 250 bar
Tyres
Heavy-duty 12-16.5 tyres for stability and traction
